SECTION 6 Communications Data for Modbus
6-8
Note 1: Not displayed on the Controller display when Alarm 3 is not assigned to the output.
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
0E48 2E24 Extraction of Square Root
Enable
H'00000000 (0): OFF
H'00000001 (1): ON
Initial
setting
0E60 2E30 Travel Time H'00000001 to H'000003E7 (1 to 999)
0F00 2F00 Alarm 1 Type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower limit alarm
H'00000002 (2): Upper limit alarm
H'00000003 (3): Lower limit alarm
H'00000004 (4): Upper and lower limit range alarm
H'00000005 (5): Upper and lower limit alarm with standby sequence
H'00000006 (6): Upper limit alarm with standby sequence
H'00000007 (7): Lower limit alarm with standby sequence
H'00000008 (8): Absolute value upper limit alarm
H'00000009 (9): Absolute value lower limit alarm
H'0000000A (10): Absolute value upper limit alarm with standby sequence
H'0000000B (11): Absolute value lower limit alarm with standby sequence
H'0000000C (12): LBA (Loop Burnout Alarm)
H'0000000D (13): PV change rate alarm
H'0000000E (14): RSP absolute value upper limit alarm
H'0000000F (15): RSP absolute value lower limit alarm
0F02 2F01 Alarm 1 Latch H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F04 2F02 Alarm 1 Hysteresis Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
Initial
setting
0F06 2F03 Alarm 2 Type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower limit alarm
H'00000002 (2): Upper limit alarm
H'00000003 (3): Lower limit alarm
H'00000004 (4): Upper and lower limit range alarm
H'00000005 (5): Upper and lower limit alarm with standby sequence
H'00000006 (6): Upper limit alarm with standby sequence
H'00000007 (7): Lower limit alarm with standby sequence
H'00000008 (8): Absolute value upper limit alarm
H'00000009 (9): Absolute value lower limit alarm
H'0000000A (10): Absolute value upper limit alarm with standby sequence
H'0000000B (11): Absolute value lower limit alarm with standby sequence
H'0000000C (12): No alarm function
H'0000000D (13): PV change rate alarm
H'0000000E (14): RSP absolute value upper limit alarm
H'0000000F (15): RSP absolute value lower limit alarm
0F08 2F04 Alarm 2 Latch H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F0A 2F05 Alarm 2 Hysteresis Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
Initial
setting
0F0C 2F06 Alarm 3 Type (See note 1.) Same settings as the alarm 2 type.
0F0E 2F07 Alarm 3 Latch (See note 1.) H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F10 2F08 Alarm 3 Hysteresis (See note 1.) Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
Initial
setting
0F18 2F0C Standby Sequence Reset H'00000000 (0): Condition A
H'00000001 (1): Condition B
Advanced
function
setting
0F1A 2F0D Auxiliary Output 1 Open in
Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F1C 2F0E Auxiliary Output 2 Open in
Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F1E 2F0F Auxiliary Output 3 Open in
Alarm (See note 1.)
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
