Omron E5CN-H Communications Manual

Com Data
for Modbus
6.1 Variable Area (Setting Range) List
6-11
Note 1: The logic of the Modbus Write Variable operation command is not affected.
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
1206 3203 Monitor/Setting Item 2 H'00000000 to H'00000010 (0 to 16)
* Same as for Monitor/Setting Item 1.
Advanced
function
setting
1208 3204 Monitor/Setting Item 3 H'00000000 to H'00000010 (0 to 16)
* Same as for Monitor/Setting Item 1.
120A 3205 Monitor/Setting Item 4 H'00000000 to H'00000010 (0 to 16)
* Same as for Monitor/Setting Item 1.
120C 3206 Monitor/Setting Item 5 H'00000000 to H'00000010 (0 to 16)
* Same as for Monitor/Setting Item 1.
1302 3301 SP Tracking H'00000000 (0): OFF
H'00000001 (1): ON
1304 3302 PID Set Automatic Selection
Data
H'00000000 (0): PV
H'00000001 (1): DV
H'00000002 (2): SP
1306 3303 PID Set Automatic Selection
Hysteresis
H'0000000A to H'0000270F (0.10 to 99.99)
1308 3304 PV Dead Band H'00000000 to H'00007E90 (0 to 32400)
130A 3305 Cold Junction Compensation
Method
H'00000000 (0): OFF
H'00000001 (1): ON
1314 330A
α H'00000000 to H'00000064 (0.00 to 1.00)
131E 330F AT Calculated Gain H'00000001 to H'00000064 (0.1 to 10.0)
1320 3310 AT Hysteresis Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'000003E7 (0.01 to 9.99)
1322 3311 Limit Cycle MV Amplitude H'00000032 to H'000001F4 (5.0 to 50.0)
1328 3314 Heater Burnout Latch H'00000000 (0): OFF
H'00000001 (1): ON
132A 3315 Heater Burnout Hysteresis H'00000001 to H'000001F4 (0.1 to 50.0)
132C 3316 HS Alarm Latch H'00000000 (0): OFF
H'00000001 (1): ON
132E 3317 HS Alarm Hysteresis H'00000001 to H'000001F4 (0.1 to 50.0)
1334 331A Bank Numbers Used H'00000000 (0): Disabled
H'00000001 (1): 2 Bank
H'00000002 (2): 4 Bank
H'00000003 (3): 8 Bank
Initial
setting
1338 331C HB ON/OFF H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
133A 331D MB Command Logic Switching
(See note 1.)
H'00000000 (0): OFF
H'00000001 (1): ON
133C 331E Input Error Output H'00000000 (0): OFF
H'00000001 (1): ON
133E 331F Input Shift Type H'00000000 (0): Temperature input 1-point shift
H'00000001 (1): Temperature input 2-point shift
1340 3320 MV at Stop and Error Addition H'00000000 (0): OFF
H'00000001 (1): ON
1342 3321 ST Stable Range H'00000001 to H'00007E90 (0.1 to 3240.0)
1344 3322 RT H'00000000 (0): OFF
H'00000001 (1): ON
1346 3323 HS Alarm Use H'00000000 (0): OFF
H'00000001 (1): ON
