Omron E5CN-H Communications Manual

Com Data
for Modbus
6.1 Variable Area (Setting Range) List
6-13
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
1400 3400 Bank 0 SP SP lower limit to SP upper limit Bank
setting
1402 3401 Bank 0 PID Set No. H'00000000 to H'00000008 (0 to 8) (0: Auto selection)
1404 3402 Bank 0 SP Ramp Set Value H'00000000 (0): OFF
H'00000001 to H'00007E90 (1 to 32400)
1406 3403 Bank 0 Alarm Value 1 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
1408 3404 Bank 0 Alarm Value Upper Limit 1 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
140A 3405 Bank 0 Alarm Value Lower Limit 1 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
140C 3406 Bank 0 Alarm Value 2 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
140E 3407 Bank 0 Alarm Value Upper Limit 2 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
1410 3408 Bank 0 Alarm Value Lower Limit 2 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
1412 3409 Bank 0 Alarm Value 3 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
1414 340A Bank 0 Alarm Value Upper Limit 3 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
1416 340B Bank 0 Alarm Value Lower Limit 3 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
141A 340D Bank 0 Soak Time H'00000001 to H'0000270F (1 to 9999)
141C 340E Bank 0 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
1420 3410 Bank 1 SP SP lower limit to SP upper limit
to
143C 341E Bank 1 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
1440 3420 Bank 2 SP SP lower limit to SP upper limit
to
145C 342E Bank 2 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
1460 3430 Bank 3 SP SP lower limit to SP upper limit
to
147C 343E Bank 3 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
1480 3440 Bank 4 SP SP lower limit to SP upper limit
to
149C 344E Bank 4 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
14A0 3450 Bank 5 SP SP lower limit to SP upper limit
to
14BC 345E Bank 5 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
14C0 3460 Bank 6 SP SP lower limit to SP upper limit
to
14DC 346E Bank 6 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
14E0 3470 Bank 7 SP SP lower limit to SP upper limit
to
14FC 347E Bank 7 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
