Omron E5CN-H Communications Manual

Com Data for CompoWay/F
3.1 Variable Area (Setting Range) List
3-5
Note: The input type can be selected to match the connected sensor.
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0000 Input Type (See note.) H'00000000 (0): Pt (
−200.0 to 850.0°C/−300.0 to 1500.0°F)
H'00000001 (1): Pt (
−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000002 (2): Pt (0.0 to 100.0
°C/0.0 to 210.0°F)
H'00000003 (3): JPt (
−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000004 (4): JPt (0.0 to 100.0
°C/0.0 to 210.0°F)
H'00000005 (5): K (
−200.0 to 1300.0°C/−300.0 to 2300.0°F)
H'00000006 (6): K (
−20.0 to 500.0°C/0.0 to 900.0°F)
H'00000007 (7): J (
−100.0 to 850.0°C/−100.0 to 1500.0°F)
H'00000008 (8): J (
−20.0 to 400.0°C/0.0 to 750.0°F)
H'00000009 (9): T (
−200.0 to 400.0°C/−300.0 to 700.0°F)
H'0000000A (10): T (
−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000B (11): E (
−200.0 to 600.0°C/−300.0 to 1100.0°F)
H'0000000C (12): L (
−100.0 to 850.0°C/−100.0 to 1500.0°F)
H'0000000D (13): U (
−200.0 to 400.0°C/−300.0 to 700.0°F)
H'0000000E (14): U (
−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000F (15): N (
−200.0 to 1300.0°C/−300.0 to 2300.0°F)
H'00000010 (16): R (0.0 to 1700.0
°C/0.0 to 3000.0°F)
H'00000011 (17): S (0.0 to 1700.0
°C/0.0 to 3000.0°F)
H'00000012 (18): B (100.0 to 1800.0
°C/300.0 to 3200.0°F)
H'00000013 (19): W (0.0 to 2300.0
°C/0.0 to 3200.0°F)
H'00000014 (20): PLII (0.0 to 1300.0
°C/0.0 to 2300.0°F)
H'00000015 (21): K (
−50.00 to 200.00°C/−50.00 to 200.00°F)
H'00000016 (22): J (
−50.00 to 200.00°C/−50.00 to 200.00°F)
H'00000017 (23): T (
−50.00 to 200.00°C/−50.00 to 200.00°F)
H'00000018 (24): Pt (
−50.00 to 200.00°C/−50.00 to 200.00°F)
H'00000019 (25): 4 to 20 mA
H'0000001A (26): 0 to 20 mA
H'0000001B (27): 1 to 5 V
H'0000001C (28): 0 to 5 V
H'0000001D (29): 0 to 10 V
Initial
setting
C3 (83) 0001 Scaling Upper Limit Scaling lower limit +1 to H'00007E90 (Scaling lower limit +1 to 32400)
C3 (83) 0002 Scaling Lower Limit H'FFFFB1E1 to scaling upper limit
−1 (−19,999 to scaling upper limit −1)
C3 (83) 0003 Decimal Point H'00000000 to H'00000003 (0 to 3)
C3 (83) 0004 Temperature Unit H'00000000 (0): °C
H'00000001 (1): °F
C3 (83) 0005 SP Upper Limit The range of values (without decimal point) is as follows:
Temperature: SP lower limit + 1 to input setting range upper limit
Analog: SP lower limit + 1 to Scaling upper limit
C3 (83) 0006 SP Lower Limit The range of values (without decimal point) is as follows:
Temperature: Input setting range lower limit to SP upper limit
−1
Analog: Scaling lower limit to SP upper limit
−1
C3 (83) 0007 PID ON/OFF H'00000000 (0): ON/OFF
H'00000001 (1): 2 PID control
C3 (83) 0008 Standard or Heating/Cooling H'00000000 (0): Standard
H'00000001 (1): Heating/cooling
C3 (83) 0009 ST H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 000A Control Period (Heating) H'00000000 (0): 0.5
H'00000001 to H'00000063 (1 to 99)
C3 (83) 000B Control Period (Cooling) H'00000000 (0): 0.5
H'00000001 to H'00000063 (1 to 99)
C3 (83) 000C Direct/Reverse Operation H'00000000 (0): Reverse operation
H'00000001 (1): Direct operation
