Omron E5CN-H Communications Manual

Com Data for CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-6
Note: The alarm function can also be used in Controllers without alarm output terminals. In this case, confirm alarm occurrences
via the status data.
Note 1: Not displayed on the Controller display when Alarm 3 is not assigned to the output.
Note 2: After communications parameters have been changed, reset the Controller to enable them.
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 000D Alarm 1 Type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower limit alarm
H'00000002 (2): Upper limit alarm
H'00000003 (3): Lower limit alarm
H'00000004 (4): Upper and lower limit range alarm
H'00000005 (5): Upper and lower limit alarm with standby sequence
H'00000006 (6): Upper limit alarm with standby sequence
H'00000007 (7): Lower limit alarm with standby sequence
H'00000008 (8): Absolute value upper limit alarm
H'00000009 (9): Absolute value lower limit alarm
H'0000000A (10): Absolute value upper limit alarm with standby
sequence
H'0000000B (11): Absolute value lower limit alarm with standby
sequence
H'0000000C (12): LBA (Loop Burnout Alarm)
H'0000000D (13): PV change rate alarm
H'0000000E (14): RSP absolute value upper limit alarm
H'0000000F (15): RSP absolute value lower limit alarm
Initial
setting
C3 (83) 000E Alarm 2 Type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower limit alarm
H'00000002 (2): Upper limit alarm
H'00000003 (3): Lower limit alarm
H'00000004 (4): Upper and lower limit range alarm
H'00000005 (5): Upper and lower limit alarm with standby sequence
H'00000006 (6): Upper limit alarm with standby sequence
H'00000007 (7): Lower limit alarm with standby sequence
H'00000008 (8): Absolute value upper limit alarm
H'00000009 (9): Absolute value lower limit alarm
H'0000000A (10): Absolute value upper limit alarm with standby
sequence
H'0000000B (11): Absolute value lower limit alarm with standby
sequence
H'0000000C (12): No alarm function
H'0000000D (13): PV change rate alarm
H'0000000E (14): RSP absolute value upper limit alarm
H'0000000F (15): RSP absolute value lower limit alarm
C3 (83) 000F Alarm 3 Type (See note 1.) Same settings as the alarm 2 type
C3 (83) 0010 Communications Unit No. (See note 2.) H'00000000 to H'00000063 (0 to 99) Communi-
cations
setting
C3 (83) 0011 Communications Baud Rate
(See note 2.)
H'00000000 (0): 1.2
H'00000001 (1): 2.4
H'00000002 (2): 4.8
H'00000003 (3): 9.6
H'00000004 (4): 19.2
H'00000005 (5): 38.4
H'00000006 (6): 57.6
C3 (83) 0012 Communications Data Length
(See note 2.)
H'00000007 (7): 7
H'00000008 (8): 8
C3 (83) 0013 Communications Stop Bits
(See note 2.)
H'00000001 (1): 1
H'00000002 (2): 2
C3 (83) 0014 Communications Parity (See note 2.) H'00000000 (0): None
H'00000001 (1): Even
H'00000002 (2): Odd
C3 (83) 0015 Bank Numbers Used H'00000000(0): Disabled
H'00000001(1): 2 Bank
H'00000002(2): 4 Bank
H'00000003(3): 8 Bank
Initial
setting
