Omron E5CN-H Communications Manual

Com Data for CompoWay/F
3.1 Variable Area (Setting Range) List
3-7
Note 1: For Controllers with two event inputs (events 1 and 2), this parameter cannot be set if the Bank Numbers Used parameter
is set to a value greater than 0.
Note 2: For Controllers with two event inputs (events 1 and 2), this parameter cannot be set if the Bank Numbers Used parameter
is set to a value greater than 1.
Note 3: For Controllers with two event inputs (events 3 and 4), this parameter cannot be set if the Bank Numbers Used parameter
is set to a value greater than 0.
Note 4: For Controllers with two event inputs (events 3 and 4), this parameter cannot be set if the Bank Numbers Used parameter
is set to a value greater than 1.
Note 5: PRST (program start) can be set even when the program pattern is set to OFF, but the function will be disabled.
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0016 Event Input Assignment 1 (See note 1.) H'00000000 (0): None
H'00000001 (1): RUN/STOP
H'00000002 (2): Auto/manual switch
H'00000003 (3): Program Start (See note 5.)
H'00000004 (4): Direct/reverse operation
H'00000005 (5): SP mode change
H'00000006 (6): 100% AT execute/cancel
H'00000007 (7): 40% AT execute/cancel
H'00000008 (8): Setting change enable/disable
H'00000009 (9): Communications writing enabled/disabled
H'0000000A (10): Alarm latch cancel
Initial
setting
C3 (83) 0017 Event Input Assignment 2 (See note 2.) H'00000000 to H'0000000A (0 to 10)
* Same as for Event Input Assignment 1.
C3 (83) 0018 Event Input Assignment 3 (See note 3.) H'00000000 to H'0000000A (0 to 10)
* Same as for Event Input Assignment 1.
C3 (83) 0019 Event Input Assignment 4 (See note 4.) H'00000000 to H'0000000A (0 to 10)
* Same as for Event Input Assignment 1.
C3 (83) 001B SP Ramp Time Unit H'00000000 (0): EU/second
H'00000001 (1): EU/minute
H'00000002 (2): EU/hour
Advanced
function
setting
C3 (83) 001D Standby Sequence Reset H'00000000 (0): Condition A
H'00000001 (1): Condition B
C3 (83) 001E Auxiliary Output 1 Open in Alarm H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
C3 (83) 001F Alarm 1 Hysteresis Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
Initial
setting
