Omron E5CN-H Communications Manual

Com Data for CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-8
Note: The alarm function can also be used in Controllers without alarm output terminals. In this case, confirm alarm occurrences
via the status data.
Note 1: Not displayed on the Controller display when Alarm 3 is not assigned to the output.
Note 2: The logic is switched only in the MB command (SYSWAY). The logic of CompoWay/F operation command code 00
(communications writing) is not affected.
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0020 Auxiliary Output 2 Open in Alarm H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
Advanced
function
setting
C3 (83) 0021 Alarm 2 Hysteresis Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
Initial
setting
C3 (83) 0022 Auxiliary Output 3 Open in Alarm
(See note 1.)
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
Advanced
function
setting
C3 (83) 0023 Alarm 3 Hysteresis (See note 1.) Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
Initial
setting
C3 (83) 0024 HB ON/OFF H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
C3 (83) 0025 Heater Burnout Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0026 Heater Burnout Hysteresis H'00000001 to H'000001F4 (0.1 to 50.0)
C3 (83) 0027 ST Stable Range H'00000001 to H'00007E90 (0.1 to 3240.0)
C3 (83) 0028
α H'00000000 to H'00000064 (0.00 to 1.00)
C3 (83) 002B Input Digital Filter H'00000000 to H'0000270F (0.0 to 999.9)
C3 (83) 002C Additional PV Display H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 002D MV Display H'00000000 (0): OFF (display of manipulated variable OFF)
H'00000001 (1): ON (display of manipulated variable ON)
C3 (83) 002E Automatic Display Return Time H'00000000 (0): OFF
H'00000001 to H'00000063 (1 to 99)
C3 (83) 002F Alarm 1 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0030 Alarm 2 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0031 Alarm 3 Latch (See note 1.) H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0032 Move to Protect Level Time H'00000001 to H'0000001E (1 to 30)
C3 (83) 0033 Input Error Output H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0034 Cold Junction Compensation Method H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0035 MB Command Logic Switching
(See note 2.)
H'00000000 (0): OFF
H'00000001 (1): ON
