Omron E5CN-H Communications Manual

Com Data for CompoWay/F
3.1 Variable Area (Setting Range) List
3-15
Variable
type
Address Parameter name Setting (monitor) value Level
C5 (85) 0000 PID 1 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
PID setting
C5 (85) 0001 PID 1 Integral Time Standard, heating/cooling, position proportional (closed):
H'00000000 to H'00007E90 (0.0 to 3240.0)
Position proportional (floating):
H'00000001 to H'00007E90 (0.1 to 3240.0)
C5 (85) 0002 PID 1 Derivative Time H'00000000 to H'00007E90 (0.0 to 3240.0)
C5 (85) 0003 PID 1 MV Upper Limit Standard: MV lower limit + 0.1 to H'0000041A
(MV lower limit + 0.1 to 105.0)
Heating/cooling: H'00000000 to H'0000041A (0.0 to 105.0)
Position proportional (closed): MV lower limit +0.1 to H'0000041A
(MV lower limit + 0.1 to 105.0)
C5 (85) 0004 PID 1 MV Lower Limit Standard: H'FFFFFFCE to MV upper limit
−0.1
(
−5.0 to MV upper limit −0.1)
Heating/cooling: H'FFFFFBE6 to H'00000000 (
−105.0 to 0.0)
Position proportional (closed): H'FFFFFFCE to MV upper limit
−0.1
(
−5.0 to MV upper limit −0.1)
C5 (85) 0005 PID 1 Automatic Selection Range
Upper Limit
Temperature: H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
Analog: H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
C5 (85) 0006 PID 1 Cooling Coefficient H'00000001 to H'0000270F (0.01 to 99.99)
C5 (85) 0007 PID 1 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
C5 (85) 0010 PID 2 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
C5 (85) 0017 PID2 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
C5 (85) 0020 PID3 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
C5 (85) 0027 PID3 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
C5 (85) 0030 PID4 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
C5 (85) 0037 PID4 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
C5 (85) 0040 PID5 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
C5 (85) 0047 PID5 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
C5 (85) 0050 PID6 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
C5 (85) 0057 PID6 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
C5 (85) 0060 PID7 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
C5 (85) 0067 PID7 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
C5 (85) 0070 PID8 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
C5 (85) 0077 PID8 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
