Omron E5CN-H Communications Manual

Com Data for CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-14
Variable
type
Address Parameter name Setting (monitor) value Level
C4 (84) 0000 Bank 0 SP SP lower limit to SP upper limit Bank
setting
C4 (84) 0001 Bank 0 PID Set No. H'00000000 to H'00000008 (0 to 8) (0: Auto selection)
C4 (84) 0002 Bank 0 SP Ramp Set Value H'00000000 (0): OFF
H'00000001 to H'00007E90 (1 to 32400)
C4 (84) 0003 Bank 0 Alarm Value 1 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
C4 (84) 0004 Bank 0 Alarm Value Upper Limit 1 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
C4 (84) 0005 Bank 0 Alarm Value Lower Limit 1 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
C4 (84) 0006 Bank 0 Alarm Value 2 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
C4 (84) 0007 Bank 0 Alarm Value Upper Limit 2 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
C4 (84) 0008 Bank 0 Alarm Value Lower Limit 2 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
C4 (84) 0009 Bank 0 Alarm Value 3 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
C4 (84) 000A Bank 0 Alarm Value Upper Limit 3 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
C4 (84) 000B Bank 0 Alarm Value Lower Limit 3 H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
C4 (84) 000D Bank 0 Soak Time H'00000001 to H'0000270F (1 to 9999)
C4 (84) 000E Bank 0 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
C4 (84) 0010 Bank 1 SP SP lower limit to SP upper limit
to
C4 (84) 001E Bank 1 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
C4 (84) 0020 Bank 2 SP SP lower limit to SP upper limit
to
C4 (84) 002E Bank 2 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
C4 (84) 0030 Bank 3 SP SP lower limit to SP upper limit
to
C4 (84) 003E Bank 3 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
C4 (84) 0040 Bank 4 SP SP lower limit to SP upper limit
to
C4 (84) 004E Bank 4 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
C4 (84) 0050 Bank 5 SP SP lower limit to SP upper limit
to
C4 (84) 005E Bank 5 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
C4 (84) 0060 Bank 6 SP SP lower limit to SP upper limit
to
C4 (84) 006E Bank 6 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
C4 (84) 0070 Bank 7 SP SP lower limit to SP upper limit
to
C4 (84) 007E Bank 7 Wait Band H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
