Omron E5CN-H Communications Manual

Com Data for CompoWay/F
3.1 Variable Area (Setting Range) List
3-13
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0073 PV/SP Display Screen Selection H'00000000 (0): PV/SP
H'00000001 (1): PV/SP/Bank No.
PV/SP/MV
H'00000002 (2): PV/SP/MV
PV/SP/Bank No.
H'00000003 (3): PV/SP/Bank No.
H'00000004 (4): PV/SP/MV
H'00000005 (5): PV/SP/Bank No.
PV/SP/Soak Time Remain
H'00000006 (6): PV/SP/MV
PV/SP/Soak Time Remain
H'00000007 (7): PV/SP/Soak Time Remain
Advanced
function
setting
C3 (83) 0074 MV Display Selection H'00000000 (0): MV (heating)
H'00000001 (1): MV (cooling)
C3 (83) 0075 PV Decimal Point Display H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0076 PV Status Display Function H'00000000 (0): OFF
H'00000001 (1): Manual
H'00000002 (2): Stop
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Alarm 1 to 3 OR status
H'00000007 (7): Heater alarm
C3 (83) 0077 SV Status Display Function H'00000000 to H'00000006 (0 to 7)
* Same as for PV Status Display Function
C3 (83) 0078 Control Output 1 ON/OFF Count Alarm
Set Value
H'00000000 to H'0000270F (0 to 9999)
C3 (83) 0079 Control Output 2 ON/OFF Count Alarm
Set Value
H'00000000 to H'0000270F (0 to 9999)
C3 (83) 0081 Valid Program Bank H'00000000 to H'00000007 (0 to 7) Initial
setting
C3 (83) 0083 Display Refresh Period H'00000000 (0): OFF
H'00000001 (1): 0.25
H'00000002 (2): 0.5
H'00000003 (3): 1.0
Advanced
function
setting
