Omron E5CN-H Communications Manual

Com Data for CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-12
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0066 PID Set Automatic Selection Hysteresis H'0000000A to H'0000270F (0.10 to 99.99) Advanced
function
setting
C3 (83) 0067 PV Rate of Change Calculation Period H'00000001 to H'000003E7 (1 to 999)
C3 (83) 0068 Automatic Cooling Coefficient Adjust-
ment
H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0069 Heater Overcurrent Use H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 006A Heater Overcurrent Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 006B Heater Overcurrent Hysteresis H'00000001 to H'000001F4 (0.1 to 50.0)
C3 (83) 006C Extraction of Square Root Enable H'00000000 (0): OFF
H'00000001 (1): ON
Initial
setting
C3 (83) 006D PF Setting H'00000000 (0): OFF
H'00000001 (1): RUN
H'00000002 (2): STOP
H'00000003 (3): RUN/STOP
H'00000004 (4): 100% AT execute/cancel
H'00000005 (5): 40% AT execute/cancel
H'00000006 (6): Alarm latch cancel
H'00000007 (7): Auto/manual
H'00000008 (8): Monitor/setting item
H'00000009 (9): Bank change
Advanced
function
setting
C3 (83) 006E Monitor/Setting Item 1 H'00000000 (0): Disable
H'00000001 (1): PV/SP/Bank No.
H'00000002 (2): PV/SP/MV
H'00000003 (3): PV/SP/soak time remain
H'00000004 (4): Proportional band (P)
H'00000005 (5): Integral time (I)
H'00000006 (6): Derivative time (D)
H'00000007 (7): Alarm value 1
H'00000008 (8): Alarm value upper limit 1
H'00000009 (9): Alarm value lower limit 1
H'0000000A (10): Alarm value 2
H'0000000B (11): Alarm value upper limit 2
H'0000000C (12): Alarm value lower limit 2
H'0000000D (13): Alarm value 3
H'0000000E (14): Alarm value upper limit 3
H'0000000F (15): Alarm value lower limit 3
H'000000010 (16): Bank No.
C3 (83) 006F Monitor/Setting Item 2 H'00000000 to H'00000010 (0 to 16)
* Same as for Monitor/Setting Item 1.
C3 (83) 0070 Monitor/Setting Item 3 H'00000000 to H'00000010 (0 to 16)
* Same as for Monitor/Setting Item 1.
C3 (83) 0071 Monitor/Setting Item 4 H'00000000 to H'00000010 (0 to 16)
* Same as for Monitor/Setting Item 1.
C3 (83) 0072 Monitor/Setting Item 5 H'00000000 to H'00000010 (0 to 16)
* Same as for Monitor/Setting Item 1.
