Omron E5CN-H Communications Manual

Com Data for CompoWay/F
3.1 Variable Area (Setting Range) List
3-11
Note 1: P.END (program end output) can be set even when the program pattern is set to OFF, but the function will be disabled.
Note 2: The output turns ON when the status of either the Control Output 1 ON/OFF Count Alarm or the Control Output 2 ON/OFF
Count Alarm turns ON.
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0050 Auxiliary Output 1 Assignment H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Program end output (See note 1.)
H'00000007 (7): Control output ON/OFF count alarm (See note 2.)
H'00000008 (8): Work bit 1
H'00000009 (9): Work bit 2
H'0000000A (10): Work bit 3
H'0000000B (11): Work bit 4
H'0000000C (12): Work bit 5
H'0000000D (13): Work bit 6
H'0000000E (14): Work bit 7
H'0000000F (15): Work bit 8
Advanced
function
setting
C3 (83) 0051 Auxiliary Output 2 Assignment H'00000000 to H'0000000F (0 to 15)
* Same as for the Auxiliary Output 1 Assignment parameter.
C3 (83) 0052 Character Select H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0053 Program Pattern H'00000000 (0): OFF
H'00000001 (1): STOP
H'00000002 (2): CONT
H'00000003 (3): LOOP
Initial
setting
C3 (83) 0054 Soak Time Unit H'00000000 (0): Minutes
H'00000001 (1): Hours
Advanced
function
setting
C3 (83) 0055 Alarm SP Selection H'00000000 (0): Set point during SP ramp
H'00000001 (1): Set point
C3 (83) 0056 Auxiliary Output 3 Assignment H'00000000 to H'0000000F (0 to 15)
* Same as for the Auxiliary Output 1 Assignment parameter.
C3 (83) 0057 Closed/Floating H'00000000 (0): Floating
H'00000001 (1): Closed
Initial
setting
C3 (83) 0058 Travel Time H'00000001 to H'000003E7 (1 to 999)
C3 (83) 0059 PV Dead Band H'00000000 to H'00007E90 (0 to 32400) Advanced
function
setting
C3 (83) 005B Manual MV Limit Enable H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 005C Direct Setting of Position Proportional
MV
H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 005D AT Calculated Gain H'00000001 to H'00000064 (0.1 to 10.0)
C3 (83) 005E AT Hysteresis Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 9.99)
C3 (83) 005F Limit Cycle MV Amplitude H'00000032 to H'000001F4 (5.0 to 50.0)
C3 (83) 0060 Remote SP Enable H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0061 Remote SP Upper limit SP lower limit to SP upper limit
C3 (83) 0062 Remote SP Lower limit SP lower limit to SP upper limit
C3 (83) 0063 SP Tracking H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0064 Remote SP Input Error Output H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0065 PID Set Automatic Selection Data H'00000000 (0): PV
H'00000001 (1): DV
H'00000002 (2): SP
