Com Data for CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-10
Note 1: After communications parameters have been changed, reset the Controller to enable them.
Note 2: P.END (program end output) can be set even when the program pattern is set to OFF, but the function will be disabled.
Note 3: The output turns ON when the status of either the Control Output 1 ON/OFF Count Alarm or the Control Output 2 ON/OFF
Count Alarm turns ON.
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 004C Communications Protocol Setting
(See note 1.)
H'00000000 (0): CompoWay/F (SYSWAY)
H'00000001 (1): Modbus
Communi-
cations set-
ting
C3 (83) 004D Send Data Wait Time (See note 1.) H'00000000 to H'00000063 (0 to 99)
C3 (83) 004E Control Output 1 Assignment When control output 1 is a linear output:
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
When control output 1 is an ON/OFF output:
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Program end output (See note 2.)
H'00000007 (7): Control output ON/OFF count alarm (See note 3.)
H'00000008 (8): Work bit 1
H'00000009 (9): Work bit 2
H'0000000A (10): Work bit 3
H'0000000B (11): Work bit 4
H'0000000C (12): Work bit 5
H'0000000D (13): Work bit 6
H'0000000E (14): Work bit 7
H'0000000F (15): Work bit 8
Advanced
function
setting
C3 (83) 004F Control Output 2 Assignment Same as for Control Output 1 Assignment.
