5 Communications Data for Modbus
5 - 14
E5@C Digital Temperature Controllers Communications Manual (H175)
* After communications parameters have been changed, reset the Digital Controller to enable them.
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
1100 3100 Protocol Setting (See
note.)
H'00000000 (0): CompoWay/F
H'00000001 (1): Modbus
Communicat
ions setting
1102 3101 Communications Unit No.
*
H'00000000 to H'00000063 (0 to 99)
1104 3102 Communications Baud
Rate *
H'00000003 (3): 9.6
H'00000004 (4): 19.2
H'00000005 (5): 38.4
H'00000006 (6): 57.6
1106 3103 Communications Data
Length *
H'00000007 (7): 7
H'00000008 (8): 8
1108 3104 Communications Stop
Bits *
H'00000001 (1): 1
H'00000002 (2): 2
110A 3105 Communications Parity * H'00000000 (0): None
H'00000001 (1): Even
H'00000002 (2): Odd
110C 3106 Send Data Wait Time * H'00000000 to H'00000063 (0 to 99)
1200 3200 PF Setting H'00000000 (0): Disabled
H'00000001 (1): Run
H'00000002 (2): Stop
H'00000003 (3): RUN/STOP
H'00000004 (4): 100% AT execute/cancel
H'00000005 (5): 40% AT execute/cancel
H'00000006 (6): Alarm latch cancel
H'00000007 (7): Auto/manual switch
H'00000008 (8): Monitor/setting item
H'00000009 (9): Digit shift key
Advanced
function
setting
1204 3202 Monitor/Setting Item 1 H'00000000 (0): Disabled
H'00000001 (1): PV/SP/multi-SP
H'00000002 (2): PV/SP/MV
H'00000003 (3): PV/SP/soak time remain
H'00000004 (4): Proportional band
H'00000005 (5): Integral time
H'00000006 (6): Derivative time
H'00000007 (7): Alarm value 1
H'00000008 (8): Alarm value upper limit 1
H'00000009 (9): Alarm value lower limit 1
H'0000000A (10): Alarm value 2
H'0000000B (11): Alarm value upper limit 2
H'0000000C (12): Alarm value lower limit 2
H'0000000D (13): Alarm value 3
H'0000000E (14): Alarm value upper limit 3
H'0000000F (15): Alarm value lower limit 3
H'00000010 (16): Alarm value 4
H'00000011 (17): Alarm value upper limit 4
H'00000012 (18): Alarm value lower limit 4
H'00000013 (19): PV/SP/Internal set point
H'00000014 (20): PV/SP/Alarm value 1
H'00000015 (21): Proportional Band (Cooling)
H'00000016 (22): Integral Time (Cooling)
H'00000017 (23): Derivative Time (Cooling)
1206 3203 Monitor/Setting Item 2 H'00000000 to H'00000017 (0 to 23)
Note: Same as for Monitor/Setting Item 1.
1208 3204 Monitor/Setting Item 3 H'00000000 to H'00000017 (0 to 23)
Note: Same as for Monitor/Setting Item 1.
120A 3205 Monitor/Setting Item 4 H'00000000 to H'00000017 (0 to 23)
Note: Same as for Monitor/Setting Item 1.
120C 3206 Monitor/Setting Item 5 H'00000000 to H'00000017 (0 to 23)
Note: Same as for Monitor/Setting Item 1.
To Next Page
