3 - 13
3 Communications Data for CompoWay/F
E5@C Digital Temperature Controllers Communications Manual (H175)
3-1 Variable Area (Setting Range) List
3
*1 The setting (monitor) range depends on the transfer output type setting. (Refer to Section 5 Parameters in
the E5
@
C Digital Temperature Controllers User's Manual (Cat. No. H174).)
*2 After communications parameters have been changed, reset the Digital Controller to enable them.
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0038 Alarm 1 ON Delay H'00000000 to H'000003E7 (0 to 999) Advanced
function
setting
C3 (83) 0039 Alarm 2 ON Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 003A Alarm 3 ON Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 003B Alarm 1 OFF Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 003C Alarm 2 OFF Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 003D Alarm 3 OFF Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 003E Transfer Output
Type
H'00000000 (0): OFF
H'00000001 (1): Set point
H'00000002 (2): Set point during SP ramp
H'00000003 (3): PV
H'00000004 (4): MV (heating)
H'00000005 (5): MV (cooling)
H'00000006 (6): Valve opening*
* Only for Position-proportional Models.
Initial
setting
C3 (83) 003F Transfer Output
Upper Limit
H'FFFFF831 to H'0000270F (−1999 to 9999)
*1
C3 (83) 0040 Transfer Output
Lower Limit
H'FFFFF831 to H'0000270F (−1999 to 9999)
*1
C3 (83) 0041 Control Output 1
Signal
H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
C3 (83) 0043 MV at Stop and
Error Addition
H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
C3 (83) 0044 Auto/Manual
Select Addition
H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0045 RT H'00000000 (0): OFF
H'00000001 (1): ON
Note: Valid only with temperature input.
C3 (83) 0046 HS Alarm Use H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0047 HS Alarm Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0048 HS Alarm
Hysteresis
H'00000001 to H'000001F4 (0.1 to 50.0)
C3 (83) 0049 LBA Detection
Time
H'00000000 to H'0000270F (0 to 9999)
C3 (83) 004A LBA Level H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
C3 (83) 004B LBA Band H'00000000 to H'0000270F
(0.0 to 999.9 for temperature input)
(0.00 to 99.99 for analog input)
C3 (83) 004C
Protocol Setting
*2
H'00000000 (0): CompoWay/F
H'00000001 (1): Modbus
H'00000002 (2): Component communications
H'00000003 (3): Host Link (FINS)
H'00000004 (4): MC protocol (Format 4)
H'00000005 (5): Dedicated protocol (Format 4)
Communi
cations
setting
C3 (83) 004D Send Data Wait
Time
*2
H'00000000 to H'00000063 (0 to 99)
To Next Page
