Nomenclature
■ E8Y PRESSURE SENSOR
Display
1 Numerical value/menu indication
Displays the measured pressure and some menu settings.
2 Unit
Shows the measuring unit. Lit unit is currently in use.
3 OUT 1 indication LED
In measurement mode, it lights when OUT 1 output is on. In
setting mode, it flashes when OUT 1 is being set.
4 OUT 2 indication LED
In measurement mode, it lights when OUT 2 output is on. In
setting mode, it flashes when OUT 2 is being set.
Operation key
5 ADJ
In measurement mode, it adjusts the Zero Point. In setting
mode, it shifts to measurement mode.
6 MODE
Selects the current number setting or menu option.
7 UP/DOWN
In measurement mode, pushing the DOWN key displays the ON
and OFF points of OUT 1; pushing the UP key displays the ON
and OFF points of OUT 2. In setting mode, the UP and DOWN
keys increase or decrease the numeric value, respectively, or
scroll through the menu options.
1
2
3
4
5
6
7
Application Examples
Filter
E8Y
E8Y
E8Y--F
N
2
Lead Frame
E8Y--F
■ DETECTION OF
FILTER
CLOGGING
■ EXHAUST FAN
ROTATION
DETECTION
■ DETECTION OF
FLOW
■ AIR FLOW
CONTROL
