E8Y E8Y
7
Precautions
■ ENVIRONMENT
• Do not use this product where explosive gas, ignitable gas,
or any other harmful gas may be present.
• Do not use beyond rated supply voltage or under AC power
supply. Explosion or fire may be caused.
• Do not mix up DC pole's wiring. Explosion or fire may be
caused.
• This product can not be used under corrosive gas or
flammable gas.
• Do not set up beside high voltage line or power line.
• Do not expose to water.
• Do not effect the product by ultrasonic vibration.
Unit: mm (inch)
■ PANEL MOUNTING BRACKET
E89-Y1 Panel Mounting Bracket (sold separately)
■ ACCESSORIES
Mounting Bracket A Mounting Bracket B
4.2 dia.
13
(0.51)
4.2
(0.17)
19
(0.75)
24 (0.94)
35 (1.38)
25 (0.98)
1.8
(0.07)
Two-3.7 dia.
30 (1.18)
22
(0.87)
22
(0.87)
26 (1.02)
Provided with E8Y
4.2 dia.
16.4 (0.65)
35 (1.38)
25 (0.98)
Two-3.7 dia.
1.8
(0.07)
Provided with E8Y
4.2
(0.17)
13 (0.51)
19.6 (0.77)
15 (0.59)
15.6
(0.61)
11.4
(0.45)
30 (1.18)
22
(0.87)
Panel Cutout Dimensions
Note: Approximate panel thickness
is 1.0 to 3.5 mm.
70
(2.76)
70
(2.76)
40
(1.57)
48
(1.89)
36
+0.5
(1.42
+0.02
)
0
0
45
+0.5
(1.77
+0.02
)
0
0
36
+0.5
(1.42
+0.02
)
0
0
45
+0.5
(1.77
+0.02
)
0
0
40 (1.57)
41.6
(1.64)
38.8 (1.53)
39.8 (1.57)
30.9 (1.22)
40
(1.57)
10.8
(0.43)
57
(2.24)
15 (0.59)
6
(0.24)
4
(0.16)
48 (1.89)
48
(1.89)
36.8 (1.45)
28.9 (1.14)
8.8
(0.35)
57
(2.24)
15 (0.59)
8
(0.31)
6
(0.24)
With Mounting 36 Panel
With Mounting 45 Panel
Cover
Guide
Frame
Holder
■ CORRECT USE
• Use within rated pressure.
• Do not mix up connecting +, – sign of pressure port. The "+"
sign is for plus pressure, the "–" sign for minus pressure.
• Do not pull the cable more than 50 N (5.1 kgf).
• Filter the gas with an appropriate air filter so that the applied
gas will be free of moisture or oil.
• When not using linear output and/or the ON/OFF output, cut
the output lead wire and cover the tip with an insulation tube
to prevent wrong connection.
To Next Page
