E8Y E8Y
6
■ CONTROLLER OF FLOW SENSOR
Vertical-mounting Type
E8Y-A5C-F03V
E8Y-A5C-F20V
Horizontal-mounting Type
E8Y-A5C-F03H
E8Y-A5C-F20H
Dimensions
Unit: mm (inch)
■ CONTROLLER OF PRESSURE SENSOR
Standard Port (Pressure Port 4.5 dia.) Type
E8Y-A2C
E8Y-A5C
E8Y-A2Y
E8Y-A5Y
Die-cast Port (Pressure Port Rc(PT) 1/8) Type
E8Y-A2C-R
E8Y-A5C-R
E8Y-A2Y-R
E8Y-A5Y-R
4.5 dia.
pressure port (-)
18
(0.71)
22 (0.87)
15 (0.59)
31 (1.22)
30
(1.18)
5 (0.20)
29.8±0.6
(1.17±0.02)
39.8 (1.57)
10
(0.39)
4.5 dia.
pressure port (+)
22
(0.87)
Four-M3 screw depth 5.2
(hole depth 8.2)
Mounting Dimensions
Two-3.7 dia.
Note: When attaching the
Mounting Bracket to
the Sensor, make
sure that each M3
screw is tightened to
a torque of 0.54 N•m
(5.5 kgf•cm) max.
22
(0.87)
31 (1.22)
30
(1.18)
5 (0.20)
17 (0.67)
18
(0.71)
29.8±0.6
(1.17±0.02)
39.8 (1.57)
10
(0.39)
Rc (PT) 1/8
pressure port (-)
22 (0.87)
Rc (PT) 1/8
pressure port (+)
22
(0.87)
Four-M3 screw depth 5.2
(hole depth 8.2)
Mounting Dimensions
Two-3.7 dia.
Note: When attaching the
Mounting Bracket to
the Sensor, make
sure that each M3
screw is tightened to
a torque of 0.54 N•m
(5.5 kgf•cm) max.
22
(0.87)
IN
OUT
31 (1.22)
13 dia.
67.3
(2.65)
47.3
(1.86)
30
(1.18)
Two-Rc (PT)
1/8 taper screw
41.3 (1.63)
14 (0.55)
Vinal-insulated round
cable 4.0 dia. 4 cores
5 (0.20)
2 m (78.7)
30 (1.18)
10 (0.39)
20 (0.79)
23 (0.91)
39.3
(1.55)
Mounting holes
(through) Two-3.7 dia.
Mounting screw
(through) Two-M3 screw
IN
OUT
31
(1.22)
13 dia.
67.3 (2.65)
47.3 (1.86)
30 (1.18)
41.3 (1.63)
14 (0.55)
7 (0.28)
Two-Rc (PT)
1/8 taper screw
5 (0.20)
2 m (78.7)
30 (1.18)
10 (0.39)
20 (0.79)
Vinal-insulated round
cable 4.0 dia. 4 cores
33.5 (1.32)
23 (0.91)
39.3 (1.55)
Mounting holes
(through)
Two-3.7 dia.
Mounting screw
(through)
Two-M3 screw
