Omron F3SJ-A series Manual

F3SJ-A
31
Dedicated External Indicator Set
F39-A01@-PAC
54
30 dia.
9 dia.
6.5 dia.
16
6
19
34
6
18
90
173
20
2
32
Material: Stainless steel
10
32 32
29.5
Four digits in the model number (protective height) − 10
Spatter Protection Cover
F39-HJ@@@@
Material: PC (transparent area)
ABS (non-transparent area)
Assembled dimensions
8-7 dia.
4-1/4 inch screws × 63
52
70
30.5
Cylindrical mounting rod (42 dia. ±1) (accessory).
61 (contact mounting)
32
24
M
34
13
102
145
L
K
Mirrors
F39-MLG@
* Following May 2018 production, products will include a
two-p
iece mirror. "K" indicates the distance to the mirror
seam.
Model L (mm) M (mm) K (mm)
F39-MLG0406 445 487---
F39-MLG0610 648 690 ---
F39-MLG0711 749 792 ---
F39-MLG0914 953 995 ---
F39-MLG1067 1,105 1,148 ---
F39-MLG1219 1,257 1,300 ---
F39-MLG1422 * 1,499 1,541 749
F39-MLG1626 * 1,702 1,744 851
F39-MLG1830 * 1,905 1,948 952
F39-MLG2134 * 2,210 2,252 1,054
67.9
35.8
(16)(12)
(625.7)
(46)
Insulated vinyl round cable 4.6 dia.
Standard length: 0.5 m
(11.8)
Setting Support Software for
the F3SJ
F39-GWUM
