Omron F3SJ-A series Manual

F3SJ-A
30
Accessories
Single-Ended Cable
Double-Ended Cable
Cable color: Gray for emitter
Black for receiver
F39-JD3A (L = 3 m)
F39-JD7A (L = 7 m)
F39-JD10A (L = 10 m)
F39-JD15A (L = 15 m)
F39-JD20A (L = 20 m)
39.5
15 dia.
L *
Insulated vinyl round cable 6.6 dia. with braided shield
8-wire (4-pair) (Cross section of conductor: 0.3 mm
2
/insulator diameter: 1.15 mm)
Standard length L
* Cables with L=3, 7, 10, 15, and 20 m are available.
Waterproof connector
Cable color: Gray for emitter
Black for receiver
F39-JDR5B (L = 0.5 m)
F39-JD1B (L = 1 m)
F39-JD3B (L = 3 m)
F39-JD5B (L = 5 m)
F39-JD7B (L = 7 m)
F39-JD10B (L = 10 m)
F39-JD15B (L = 15 m)
F39-JD20B (L = 20 m)
15 dia. 15 dia.
39.5 43L
Insulated vinyl round cable 6.6 dia. with braided shield
8-wire (4-pair) (Cross section of conductor: 0.3 mm
2
/insulator diameter: 1.15 mm)
Standard length L
Waterproof connector Waterproof connector
Simple Wiring Connector
F39-CN5
24.7
12
13.6 13.6
8 dia. (SPOT FACING 2)
4.5 dia.
(52)
32.1
10
17.7
18
Control Unit
F3SP-B1P
63
45 max.
43
5.6
111 max.
4.6 dia.
35
±0.3
2-4.2 dia. or M4
5
84
±0.3
2.3R
10.5
9
9
76 max.
13 max.
7 × 5=35
5.9
24-M3
Receiver
Emitter
91
Mounting screw holes
Laser Pointer
F39-PTJ
101±5
76
40
50
15.9 dia.
Power button
40.6
32.7
23.1
Optical axis
32
