No.20S046-00
17/62
FS-C4KU7DGES-F / FS-C4KU7DGES-M42 / FS-C2KU7DGES-F / FS-C2KU7DGES-M42 / FS-C2KU7DGES-C
Product Specifications and Use’s Guide
7) Sensor Read Out
FVAL (Frame valid, which is image output period, HIGH state) signal is out.
8) Acquisition Trigger Wait
While image transferring from camera to PC, “Low” state of signal is out. The signal state will be
“High” after finish image transferring.
9) Acquisition Trigger Internal
The image transferring starts signal is out.
10) Exposure Active
While camera exposing, “HIGH” state of signal is out. The signal state will be “LOW” after finish
exposing.
11) Timer 0 Active
Selected signal at “Timer0 Counter” is out.
When signal synchronizing with “Exposure Active” signal, signal can use for strobe control.
12) Timer 1 Active
Selected signal at “Timer1 Counter” is out.
When signal synchronizing with “Exposure Active” signal, signal can use for strobe control.
13) Software Signal 0
Selected signal for “Software Signal 0” at “Software Signal Control” is out.
14) Software Signal 1
Selected signal for “Software Signal 1” at “Software Signal Control” is out.
15) Logic Block 0
“Logic Block 0” signal is out.
16) Pulse Per Second
“Pulse / second” signal (50% Duty, 1 Hz interval) is out.
17) Line0
Debounced Line0 signal is out.
18) Line1
Debounced Line1 signal is out.
19) Line2
Debounced Line2 signal is out.
20) Frame Timeout
“HIGH” state signal is output when frame does not finish after Frame Timeout is passed.
21) Action 0
Selected signal at “Action Control” is out.
To Next Page
