Omron H3DS Series User Manual

H3DS-M/-S/-A
H3DS-M/-S/-A
13
Dimensions
Note: All units are in millimeters unless otherwise indicated.
H3DS-ML/-SL/-AL
Surface color: Light gray 5Y7/1 (OMRON)
H3DS-MLC/-SLC/-ALC
17.5
73
80
68
44
45
Installation
Terminal Arrangement
H3DS-MLC
15
18 16
18 16 A2
A1 15
18 A2
A1 15
(see note 1)
H3DS-SLC/-ALC
B1
L
(see note 1)
16
15
18 16
15
18 16
A1 15
15
18 16
H3DS-ML
B1
18 16 A2
A1 15
18 16 A2
H3DS-SL/-AL
Note: 1. DC supply voltage does not require the designation of polarity .
2. The contact symbol for the H3DS is indicated with because it of fers multiple operating modes and is dif ferent from the delayed
contact for conventional timers.

Omron H3DS Series Specifications

General

Type	Solid-state Timer
Operating Temperature	-10°C to 55°C
Output Type	Relay
Terminal Type	Screw terminals
Storage Temperature	-25°C to 65°C
Mounting	DIN Rail
Output	SPDT
Functions	On-Delay, Off-Delay, Interval, One-Shot
Protection Rating	IP20
Contact Form	SPDT
