H3DS-M/-S/-A
H3DS-M/-S/-A
6
Specifications
General
Item H3DS-MLj H3DS-SLj H3DS-ALj
Operating
mode
A:
ON-delay (Signal or Power)
B:
Flicker OFF start (Signal or Power)
B2: Flicker ON start (Signal or Power)
C:
Signal ON/OFF-delay
D:
Signal OFF-delay
E:
Interval (Signal or Power)
G:
Signal ON/OFF-delay
J:
One-shot (Signal or Power)
A: ON-delay
B2: Flicker ON start
E: Interval
J: One-shot
A: ON-delay (fixed)
Input type
V
oltage input
---
Output type Relay: SPDT
External
connections
Screw terminal, screwless spring terminal
T
erminal block
Screw terminal type:
Clamps two 2.5-mm
2
max. bar terminals without sleeves.
Screwless spring terminal type:
Clamps two 1.5-mm
2
max. bar terminals without sleeves.
T
erminal screw
tightening torque
0.98 N
S
m max.
Mounting method
DIN track mounting (see note)
Attachment
Nameplate label
Approved standards
UL508, CSA C22.2 No.14
Conforms to EN61812-1, IEC60664-1 (VDE01
10) 4 kV/2, VDE0106/P100
Output category according to IEC60947-5-1 (AC-13; 250 V 5 A/AC-14; 250 V 1 A/AC-15; 250 V 1 A/DC-13; 30
V 0.1 A/DC-14; 30 V 0.05 A)
Note:
Can be mounted to 35-mm DIN T
rack with a plate thickness of 1 to 2.5 mm.
Time Ranges
Time
scale display
T
ime range
0.1 s
0.1 to 1.2 s
1 s
1 to 12 s
0.1 m
0.1 to 1.2 min
1 m
1 to 12 min
0.1 h 0.1 to 1.2 h
1 h 1 to 12 h
10 h 10 to 120 h
Note:
When the time setting dial is set to “0” for any time scale, the output will operate instantaneously
.
Ratings
Rated
supply voltage
(see notes 1 and 2)
24 to 230 V
AC (50/60 Hz)/24 to 48 VDC
Operating voltage range
85% to 1
10% of rated supply voltage
Power reset
Minimum power-off time: 0.1 s
Reset voltage
2.4 V
AC/DC max.
Power consumption (see note 3)
AC:
32 V
A max./3.0 W max. (typical: 30 V
A/2.7 W) at 230 V
AC
14 V
A /2 2 W (t i l 13 V
A/2 1 W) t 100 t 120 V
AC
14 V
A max./2.2 W max. (typical: 13 V
A/2.1 W) at 100 to 120 V
AC
DC:
0.7 W max.
t
pical: 0.6 W
at 24 VDC
.
.
.
1.4 W max. (typical: 1.3 W) at 48 VDC
V
oltage input
Max. permissible capacitance between inputs lines (terminals B1 and A2): 2,000 pF
Load connectable in parallel with inputs (terminals B1 and A1).
H-level:
20.4 to 253 V
AC/20.4 to 52.8 VDC
L-level:
0 to 2.4 V
AC/DC
Control output
Contact output:
5 A at 250 V
AC with resistive load (cosφ
= 1)
5 A at 30 VDC with resistive load (cos
φ
= 1)
Ambient temperature
Operating:–10°
C to 55
°
C (with no icing)
Storage: –25°
C to 65
°
C (with no icing)
Ambient humidity
Operating: 35% to 85%
Note: 1.
DC ripple rate: 20% max.
2. Since
an inrush current of 0.4 A will occur when using the power supply voltage at 24 VDC, pay careful attention when turning on or
off
the power supply to the T
imer with a solid-state output such as a sensor
.
To Next Page
