H3DR-H
H3DR-H
100
Solid-state Power OFF-delay Timer
H3DR-H
DIN 22.5-mm Solid-state Power
OFF-delay Timer
High immunity to invertor noise.
Long power OFF-delay times;
S-series: up to 12 seconds,
L-series: up to 120 seconds.
RC
Ordering Information
Supply voltage S-series L-series
100 to 120 VAC H3DR-H H3DR-H
200 to 240 VAC
24 VAC/DC
48 VAC/DC
Note: Specify both the model number and supply voltage when ordering.
Example: H3DR-H 24 VAC/DC S
Supply voltage
Time span code
Model Number Legend:
H3DR-
j
1
1. Classification
H: Power OFF-delay timer
Specifications
General
Item H3DR-H
Operating mode Power OFF-delay
Terminal block 5 terminals used
Operating/Reset method Instantaneous operation/Time-limit reset
Output type Relay output (SPDT)
Mounting method DIN track mounting
Approved standards UL508, CSA C22.2 No.14
Conforms to VDE0435/2021 C/250, VDE0110, VDE0106/P100
Conforms to EN50081-2, prEN50082-2
Attachment Name plate
