Motor Timer STP
Best-selling Motor Timer with High
Repeat Accuracy
Accurate and stable operation.
Long life (1,000,000 mechanical operations).
Operating time is changeable at any time during
operation.
No restriction on mounting direction.
Wide variety of timing ranges form 5 s to 24 hrs.
Equipped with operation indicator for self-resetting
type.
RC
Ordering Information
Operation/resetting
t
Internal
t
i
Time-limit
t
t
Instantaneous
t
t
Moving pointer
p
/
g
system connection contact contact
Not provided Provided
Surface
mounting
(see note 4)
Flush
mounting
Surface
mounting
(see note 4)
Flush
mounting
Time-limit operation/
self-resetting
Parallel
motor and
c
l
u
t
c
h
SPDT SPST-NO
(see note 3)
STP-N STP-Y STP-NM STP-YM
clutch
connection
SPST-NO STP-NH --- --- STP-YMH
SPDT STP-ND --- --- ---
Separate
m
o
t
o
r
a
n
d
SPST-NO
(
s
e
e
n
o
t
e
3
)
STP-N2 --- --- ---
Time-limit operation/
electric resetting
motor an
d
clutch
connection
(
see note 3
)
STP-NR --- STP-NMR STP-YMR
Note: 1. Specify both the model number and supply voltage when ordering.
2. If a UL or CSA recognized type is required, please specify the model number by adding suffix “-US”.
3. Circuit is also used for the operating power circuit.
4. The surface mounting type can be used as a flush mounting type by attaching an exclusive adapter (Y92F-50) to the timer.
