Weekly Time Switch H5L
Easy Programming with Large LCD
Display and Interactive Functions
Programming for 24 hrs x 7 days using just five
switches.
Sixteen program steps available.
Power supply freely selectable from 100 to
240 VAC.
15 A control outputs from first and second circuits.
Manual ON/OFF switching for control output
without changing the program.
Memory protection during power failure for up to 10
years.
Cycle operation possible.
Surface, flush, or track mounting.
RC+
Ordering Information
Wiring Backup power supply function for
memory protection
No. of program steps Model
Screw terminals Provided (approx. 10 years at 25
"
C) 16 in total of first and second circuits (Each ON
or OFF is considered to be one step.)
H5L-A
Specifications
Time Ranges
Rated time Time setting range Time division
24 hrs x 7 days 00:00 to 23:59 1min
Ratings
Rated supply voltage 100 to 240 VAC (50/60 Hz)
Operating voltage range 85% to 110% of rated supply voltage
Power consumption 7VA
Control outputs 15 A at 250 VAC, resistive load at 50
"
C
12 A at 250 VAC, resistive load at 55
"
C
