Solid-state Timer H3BH
DIN-sized(48x48mm)Power
OFF-delay Timer
Long-duration power OFF-delay Timer
(S series: 0.5 to 10 s, M series: 0.5 to 10 min)
Forced resetting type available, which helps
expand the application range of the power
OFF-delay Timer.
Equipped with relay ON indicator.
RC
Ordering Information
Operation/resetting
t
Terminal Time-limit contact Mounting method
p
/
g
system
Surface mounting/
track mounting
Flush mounting
Instantaneous operation/
time-limit resetting
8-pin round socket DPDT H3BH-8 (with P2CF-08
socket)
H3BH-8 (with Y92F-30
adapter)
Instantaneous operation/
time-limit resetting/
forced resetting
SPDT H3BH-8R (with P2CF-08
socket)
H3BH-8R (with Y92F-30
adapter)
Note: Specify both the model number and supply voltage when ordering.
Accessories (Order Separately)
Same as H3BA except for the following.
Timer
Track mounted socket
(
t
1
)
Back connecting socket
(see note 1)
Solder terminal Screw terminal
H3BH-8/-8R P2CF-08 PL08 P3G-08
Note: Track mounted socket can be used as a front connecting socket.
Replacements
H3BH Replacement model Reference page
H3BH-8 H3CR-H8L 51
H3BH-8R H3CR-H8RL
Specifications
Time Ranges
Time unit S series M series
s min
Setting 0.5 0.05 to 0.5
1 0.1to1
5 0.5to5
10 1to10
Min. power ON time 0.1 s min. 2smin.
Min. interval for forced reset operation 10 s min.
Min. interval for power ON operation 10 s min.
