273
Rotary Timer H5RA
Replaces Old-fashioned Rotary Cams
for Repeat Pattern Control on
Conveyors, Wrapping and Food
Packaging Machines, etc.
Choose between 8 or 16 control outputs.
Store three separate control programs.
Fine-adjust cycle time without changing the
program.
Wide supply voltage range: 100 to 240 VAC.
Wide time setting range: 9.99 s to 99.9 hrs.
Built-in battery protects program memory.
Quick, accurate response.
Easy-to-read LED status and setting displays.
Ordering Information
Operation method No. of control outputs Mounting method Model
Continuous repetition 8 Surface mounting H5RA-8
16 H5RA-16
Specifications
Time Ranges
Rated time Setting range
Cycle Output
9.99 s 0.02 to 9.99 s 0.00 to 9.98 s (see note)
99.9 s 0.2 to 99.9 s 0.0 to 99.8 s (see note)
999 s 2to999s 0 to 998 s (see note)
99.9 min 0.2 to 99.9 min 0.0 to 99.8 min (see note)
999 min 2to999min 0 to 998 min (see note)
99.9 hrs 0.2 to 99.9 hrs 0.0 to 99.8 hrs (see note)
Note: Must be within the set cycle.
Ratings
Rated supply voltage 100 to 240 VAC (50/60 Hz)
Operating voltage range 90% to 110% of rated supply voltage (90 to 264 VAC, (50/60 Hz))
Power consumption 10 W max.
Control outputs 100 mA at 30 VDC, solid-state (open collector)
