Specifications
Item
H5CL-A
j
(AC models) H5CL-AD
j
(DC models)
Classification Digital timer
Mounting DIN track, surface, and flush mounting Flush mounting
External connections Socket Screw terminals
Enclosure ratings Panel surface: IEC IP66 and NEMA Type 4 (indoors) when Y92S-29 rubber packing is used.
EMC Emission Enclosure: EN55011 Group 1 class A
Emission AC Mains: EN55011 Group 1 class A
Immunity ESD: IEC801-2: 4 kV contact discharge (level 2)
8 kV air discharge (level 3)
Immunity RF-interference: ENV50140: 10 V/m (80 MHz to 1 GHz) (level 3)
Immunity Conducted Disturbance: ENV50141: 10 V (0.15 to 80 MHz) (level 3)
Immunity Burst: IEC801-4: 2 kV power-line (level 3)
2 kV I/O signal-line (level 4)
Approved standards UL 508, CSA C22.2 No.14
Conforms to EN50081-2, prEN50082-2
Digits 4 digits (zero suppress method)
Max. time settings 9.999 s (0.001-s unit), 99.99 s (0.01-s unit), 999.9 s (0.1-s unit), 9999 s (1-s unit),
99 min 59 s (1-s unit), 999.9 min (0.1-min unit), 99 h 59 min (1-min unit), 999.9 h (0.1-h unit)
Display modes Up (increment) and Down (decrement) (selectable)
Input signals Start, gate, reset, and key protection
Input method No-voltage input: via NPN transistor or switching of contact
Operating modes A (signal ON-delay), F (accumulative operation) (selectable)
Reset system Power reset (A (signal ON-delay) mode only), external, manual resets
Sensor waiting time 216 ms typ., 250 ms max. (Control output is turned OFF and no input is accepted during
sensor waiting time.)
External power supply 50 mA at 12 VDC (
!
10%) ---
Display 7-segment LEDs (12 mm high, red LEDs for the present value, and 8 mm high, green LEDs for
the set value)
Memory backup EEP-ROM (overwritten 200,000 times min.), which can store data for 20 years min.
Case Light gray (Munsell 5Y7/1)
Ratings
Item
H5CL-A
j
(AC models) H5CL-AD
j
(DC models)
Rated supply voltage 100 to 240 VAC, 50/60 Hz 12 to 24 VDC (permissible ripple: 20% (p-p) max.)
Operating voltage range 85 to 264 VAC, 50/60 Hz 10.8 to 26.4 VDC
Current consumption Approx. 10 VA Approx. 3 W
Start, reset, gate inputs Min. pulse width: 1 ms/20 ms (selectable, same for all three inputs)
Key protection input Response time: 1 s max.
Power reset Min. power opening time: 0.5 s (excluding F (accumulative operation) mode)
Control output Contact output: SPDT, 3 A at 250 VAC, resistive load (cos
%
=1) (G6B-2114P-US-U used)
Min. applicable load: 10 mA at 5/24 VDC (P level, for reference value)
Transistor output: NPN open collector, 100 mA max. at 30 VDC max.,
residual voltage 1.5 VDC max.
