Omron H5CN User Manual

H3CR-A
H3CR-A
26
Dimensions
Note: All units are in millimeters unless otherwise indicated.
H3CR-A
H3CR-AS
H3CR-A8
H3CR-A8S
H3CR-A8E
11 pins
48
48
66.6
52.3
15
6
39 dia. 44.8 x 44.8
0.7
8pins
48
66.6
48
15
6
52.3
0.7
39 dia.
44.8 x 44.8
H3CR-A8EL
48
48
8pins
78
15
6
63.7
0.7
39 dia.
44.8 x 44.8
Dimensions with Set Ring
Dimensions with Flush Mounting Adaptor
Y92F-30
Panel Cutout
Note: The adapters for two or more timers mounted in a vertical line are different in
orientation from those mounted in a horizontal line.
N can be obtained as follows (n: the number of H3CR models arranged side by side)
Without a Cover: N = (48n - 2.5)
+1
/
-0
With the Protective Cover: N = (51n - 5.5)
+1
/
-0
With the Panel Cover: N = (50n - 4.5)
+1
/
-0
0.5 R max.
45
+0.6
-- 0
45
+0.6
-- 0
(N)
Time setting ring Panel cover
50
16.5
50
42 dia.
58 52
42
48
Panel
