H3BA

289

Installation

Terminal Arrangement

H3BA H3BA-FA

Note: 1. *G: Gate:

*S: Start:

*R: Reset:

2. Conventional time-limit contactsare symbolizedas .

However, the contacts of H3BA are symbolized as

because timer has four operation modes.

Refer to

“Application Examples”

Note: 1. *G: Gate:

*S: Start:

*R: Reset:

2. Conventional time-limit contacts are symbolized as .

However, the contacts of H3BA-FA are symbolized

as because timer has four operation modes.

Refer to

“Application Examples”

(See

note 2)

** *

(See

note 2)

** *

(See

note 2)

H3BA-8H H3BA-8
