H3BA
H3BA
291
Application Examples
StandardtypeH3BAisusedforthefollowingapplicationexamples.Intheschematicdiagrams,eachthicktheindicatesthewiringnecessaryfor
selecting the desired operation mode.
ON-delay Operation (A Mode)
Power-ON Start/Power-OFF Reset Signal Start/Signal Reset
Integrating Operation by Gate Signal
Signal ON-/OFF-delay Operation (C Mode)
