Selection Guide
3
Classification Solid-state Timer
Model H3DR-F H3DR-G H3DR-H
Features DIN 22.5-mm Solid-state Twin
Timers
DIN 22.5-mm Solid-state
Star-delta Timers
DIN 22.5-mm Solid-state Power
OFF-delay Timers
Appearance and dimensions
22.5
75
100
22.5
75
100
22.5
75
100
Time range (60 Hz) 0.1 s to 12 h 1to120s 0.1 to 120 s
Supply voltage 100 to 240 VAC (50/60 Hz),
48 VAC (50/60 Hz),
24 VAC/VDC (50/60 Hz),
12 VDC
100 to 240 VAC (50/60 Hz),
48 VAC (50/60 Hz),
24 VAC/VDC (50/60 Hz)
100/110/120 VAC (50/60 Hz),
200/220/240 VAC (50/60 Hz),
24 VAC/VDC (50/60 Hz),
48 VAC/VDC (50/60 Hz)
Power consumption 8.2 VA, 1.7 VA, 1.3 VA/0.6 W,
0.4 W
11 VA, 1.2 VA, 0.9 VA/0.45 W 0.5 VA, 0.8 VA, 0.17 VA/0.13 W,
0.36 VA/0.34 W
Accuracy of operating time
!
1% max.
!
1% max.
!
1% max.
Control output 5 A at 250 VAC 5 A at 250 VAC 5 A at 250 VAC
Contact
f
i
t
i
Time-limit SPDT SPST-NO SPDT
configuration
Instantaneous --- --- ---
Life expectancy 20 x 10
6
operations 20 x 10
6
operations 10 x 10
6
operations
EMC
Conforms to EN50081-2,
prEN50082-2
Conforms to EN50081-2,
prEN50082-2
Conforms to EN50081-2,
prEN50082-2
Approved standards UL, CSA, conforms to VDE UL, CSA, conforms to VDE UL, CSA, conforms to VDE
Page 90 95 100
Classification Solid-state Timer
Model H3CA H3Y H3M
Features DIN-sized (48 x 48 mm, 45 x
75 mm) Timer with digital
setting and LCD display -
multifunctions
Subminiature Timer
incorporating exclusive IC ideal
for sequence control
Solid-state Timer with variable
time ranges
Appearance and dimensions
48
48
89
28
21.5
50
40
67.1
Time range (60 Hz) 0.1 s to 9.990 h 0.5sto3h 0.05 to 30 h
Supply voltage 24 to 240 VAC (50/60 Hz),
12 to 240 VDC
100, 110, 120, 200, 220, or
240 VAC (50/60 Hz),
12, 24, 48, 100, or 110 VDC
100/110/120, 200/220/
240 VAC (50/60 Hz),
12, 24, 48, 100, or 110 VDC
Power consumption 2to10VA,1to2W 2VA,2W 5VA/2W,2W
Accuracy of operating time
!
0.3%
!
0.05 s
!
2%
!
1%
Control output 3 A at 250 VAC 5 A at 250 VAC 5 A at 250 VAC
Contact
configuration
Time-limit SPDT SPDT, DPDT DPDT, 3PDT,
4PDT
Solid-state DPDT SPDT
c
o
g
u
a
t
o
Instantaneous --- SPDT --- --- SPDT
Life expectancy 10 x 10
6
operations 10 x 10
6
operations 20 x 10
6
operations
EMC ---
Conforms to EN50081-2,
prEN50082-2 (except IEC801-4)
---
Approved standards UL, CSA, SEV UL, CSA UL, CSA
Page 109 123 132
