Multifunction Digital Timer H5CX-A/-L 3
Model Number Structure
■ Model Number Legend
1. Type classifier
A: Standard type
L: Economy type
2. External connection
None: Screw terminals
8: 8-pin socket
11: 11-pin socket
3. Output type
None: Contact output
S: Transistor output
4. Supply voltage
None: 100 to 240 VAC 50/60 Hz
D: 12 to 24 VDC/24 VAC 50/60 Hz
5. Case color
None: Black
G: Light gray (Munsell 5Y7/1): Produced upon request.
Ordering Information
■ List of Models
Note: Depending on the wiring, unwanted current from the AC power supply may occasionally burn out internal parts. H5CX-A/-L (except for
H5CX-A11/-A11S) models do not have a transformer. Therefore, the power supply and input circuit are not insulated. Refer to Safety Pre-
cautions (H5CX-A/-L) on page 49 for wiring details. The power supply and input circuit for H5CX-A11/-A11S models have basic insulation.
■ Accessories (Order Separately)
Note 1. Supplied with H5CX-A@ models (except for H5CX-A11@ and H5CX-L8@ models).
2. Y92A-48G is a finger-safe terminal cover attached to the P3G-08 or P3GA-11 Socket.
1 2 3 4 5
H5CX-@@@@-@
Output type Supply voltage Models
Standard type Economy type
Screw terminals 11-pin socket 8-pin socket
Contact output 100 to 240 VAC H5CX-A H5CX-A11 H5CX-L8
12 to 24 VDC/24 VAC H5CX-AD H5CX-A11D H5CX-L8D
Transistor output 100 to 240 VAC H5CX-AS H5CX-A11S H5CX-L8S
12 to 24 VDC/24 VAC H5CX-ASD H5CX-A11SD H5CX-L8SD
Name Models
Flush Mounting Adapter (See note 1.) Y92F-30
Waterproof Packing (See note 1.) Y92S-29
Track Mounting/
Front Connecting Socket
8-pin P2CF-08
8-pin, finger-safe type P2CF-08-E
11-pin P2CF-11
11-pin, finger-safe type P2CF-11-E
Back Connecting Socket 8-pin P3G-08
8-pin, finger-safe type P3G-08 with Y92A-48G (See note 2.)
11-pin P3GA-11
11-pin, finger-safe type P3GA-11 with Y92A-48G (See note 2.)
Hard Cover Y92A-48
Soft Cover Y92A-48F1
Mounting Track 50 cm (l)
´ 7.3 mm (t) PFP-50N
1 m (l)
´ 7.3 mm (t) PFP-100N
1 m (l)
´ 16 mm (t) PFP-100N2
End Plate PFP-M
Spacer PFP-S
