36 2-stage Digital Timer H5CX-B
Model Number Structure
■ Model Number Legend
1. Type classifier
B: 6-digit display type
2. Stage setting
W: 2-stage setting
3. Output type
S: Transistor output
4. Supply voltage
D: 12 to 24 VDC
Ordering Information
■ List of Models
■ Accessories (Order Separately)
Note: Supplied with H5CX-BWSD.
1 2 3 4
H5CX-BWSD
Output type Supply voltage 6-digit display
Screw terminals
Transistor 12 to 24 VDC H5CX-BWSD
Name Models
Flush Mounting Adapter (See note.) Y92F-30
Waterproof Packing (See note.) Y92S-29
Hard Cover Y92A-48
Soft Cover Y92A-48F1

Omron H5CX Specifications

General

Time Range	0.001 s to 9999 h
Mounting Method	Flush mounting
Output Type	Relay or Transistor
Control Output	Relay or Transistor
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Input Type	NPN or PNP
Power Supply Voltage	24V AC/DC, 100-240V AC
Operating Voltage Range	85% to 110% of rated voltage
Operating Modes	ON-delay, One-shot, Interval
Contact Rating	5 A at 250 VAC
Mounting	Panel
Dimensions	48 x 48 mm
Protection Structure	IP66 (front panel)
