Omron H5CX User Manual

Multifunction Digital Timer H5CX-A/-L 33
■ List of Settings
Fill in your set values in the set value column of the following tables and utilize the tables for quick reference.
Timer/Twin Timer Selection Mode
Settings for Timer Operation
Run Mode when Output Mode Is Not Z
Run Mode when Output Mode = Z
Function Setting Mode
Parameter
name
Parameter Setting range Default value Unit Set value
Timer/Twin Tim-
er selection
func tim/twin tim ---
DIP switch moni-
tor
dip on/off off ---
Parameter name Parameter Setting range Default value Unit Set value
Present value,
set value
Set value --- 0.00 to 99.99 (Time range: --,--s) 0.00 s
--- 0.0 to 999.9 (Time range: ---,-s) 0.0 s
--- 0 to 9999 (Time range: ----s) 0 s
--- 0:00 to 99:59 (Time range: --min--s) 0:00 min; s
--- 0.0 to 999.9 (Time range: ---,-min) 0.0 min
--- 0 to 9999 (Time range: ----min) 0 min
--- 0:00 to 99:59 (Time range: --h--min) 0:00 h; min
--- 0.0 to 999.9 (Time range: ---,-h) 0.0 h
--- 0 to 9999 (Time range: ----h) 0 h
--- 0.000 to 9.999 (Time range: -,---s) 0.000 s
Present value --- Same as set value Same as left Same as left
Parameter name Parameter Setting range Default value Unit Set value
Present value,
ON duty ratio
Cycle time --- 0.00 to 99.99 (Time range: --,--s) 0.00 s
--- 0.0 to 999.9 (Time range: ---,-s) 0.0 s
--- 0 to 9999 (Time range: ----s) 0 s
--- 0:00 to 99:59 (Time range: --min--s) 0:00 min; s
--- 0.0 to 999.9 (Time range: ---,-min) 0.0 min
--- 0 to 9999 (Time range: ----min) 0 min
--- 0:00 to 99:59 (Time range: --h--min) 0:00 h; min
--- 0.0 to 999.9 (Time range: ---,-h) 0.0 h
--- 0 to 9999 (Time range: ----h) 0 h
--- 0.000 to 9.999 (Time range: -,---s) 0.000 s
ON duty ratio --- 0 to 100 0 %
Present value,
cycle time
Present value --- Same as cycle time above Same as left Same as left
Present value --- Same as cycle time above Same as left Same as left
Parameter name Parameter Setting range Default
value
Unit Set value
Time range timr --.--s/---.-s/----s/--min--s/---.-min/----min/--
h--min/---.-h/----h/-.---s
--.--s ---
Timer mode timm up/down up ---
Output mode outm a/a-1/a-2/a-3/b/b-1/d/e/f/=a---
Output time otim hold/0.01 to 99.99 hold s
Input signal width iflt 20ms/1ms 20ms ---
NPN/PNP input mode imod npn/pnp npn ---
Display color colr red/org/r-o/o-r red ---
Key protect level kypt kp-1/kp-2/kp-3/kp-4/kp-5 kp-1 ---

Omron H5CX Specifications

General

Time Range	0.001 s to 9999 h
Mounting Method	Flush mounting
Output Type	Relay or Transistor
Control Output	Relay or Transistor
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Input Type	NPN or PNP
Power Supply Voltage	24V AC/DC, 100-240V AC
Operating Voltage Range	85% to 110% of rated voltage
Operating Modes	ON-delay, One-shot, Interval
Contact Rating	5 A at 250 VAC
Mounting	Panel
Dimensions	48 x 48 mm
Protection Structure	IP66 (front panel)
