Omron H7BX User Manual

H7BX
7
Nomenclature
Dimensions (Unit: mm)
Counter
Counter
Dimensions with Flush Mounting Adapter
Accessories (Order Separately)
O
M
R
O
N
C
o
rp
o
r
a
ti
o
n
CO
U
N
T
E
R
H7
B
X
-
A
M
A
D
E
I
N
C
H
I
N
A
L
o
t
N
o
.
X
X
X
X
X
X
1
2
3
6
7
8
10
4
5
11
9
12
1 6
to
Indicators
1 Reset Indicator (Orange)
2 Key Protection Indicator (Orange)
3 Control Output Indicator (Orange)
OUT: One stage
OUT1, OUT2: Two stages
Lit when the reset input (1) or reset key is ON.
Operation Keys
9 Mode Key
Used to switch mode and setting items.
10 Reset Key
11 Up Keys:
Switches
12 DIP Switch
5 Set Value (Sub-display)
4 Present Value (Main Display)
Character height: 13.5 mm (Red/green selectable)
Character height: 9 mm (Green)
7 Total Count Indicator (Green)
Lit when the total count value is displayed.
8 Batch Indicator (Green)
Lit when the batch count value is displayed.
6 Set Value 1 and 2 Stage Indicators (Green)
ON
12345 6 7 8
67.6 × 67.6
M3.5 terminal screw
(effective length: 6 mm)
72
72
100
6
Note: M3.5 terminal screws
(effective length: 6 mm).
H7BX-A@@
72
72
69 × 69
M3.5 terminal screw
(effective length: 6 mm)
102
5 + panel thickness
Panel
6
H7BX-A@@
(The flush mounting adapter is supplied with the H7BX.)
Panel Cutouts
Panel cutouts are as shown below
(according to DIN 43700).
82 min.
100 min.
68
+0.7
−0
68
+0.7
−0
Note: The mounting panel
thickness must be 1 to 5 mm.
Soft Cover
Y92A-72F1
Terminal Cover *
Y92A-72T
(VDE0106/T100)
Product Protection for Use in
Environments Subject to Water or Oil
The panel surface has a protective
structure so that the internal circuits will
not be adversely affected if drops of water
penetrate the gaps between the keys. If,
however, there is a possibility of water or
oil being present on the operator's hands,
mount the optional Soft Cover.
The Soft Cover ensures protection
equivalent to IP54. Do not, however, use
the H7BX in locations where it would come
into direct contact with oil.
Note: Depending on the operating
environment, the condition of resin parts
may deteriorate, and may shrink or
harden. Therefore, it is recommended
that resin parts are replaced regularly.
Hard Cover
Y92A-72
* Supplied with the H7BX.
