H7CX (Tachometer Function)H7CX (Tachometer Function)
■ Settings for Advanced Functions
Note: When using as a tachometer, switch to the tachometer configuration using the procedure given on page 31.
(30Hz) (10kHz)
(99.9s)(0.0s)
(99.9s)(0.1s)
(99.999)(1.000)(0.001)
(KP-1) (KP-2) (KP-3) (KP-4) (KP-5)
∼
∼
∼
∼
Set each setting item using the keys.
(See note 2.)
(See note 1.)
3s min.
3s min.
Power ON
Run modeFunction setting mode
Note: 1. If the mode is switched to the function setting mode during operation, operation will
continue.
2. Changes made to settings in function setting mode are enabled for the first time when
the mode is changed to run mode. Also, when settings are changed, the counter is re-
set (measured values initialized and output turned OFF) on returning to run mode.
The characters displayed in reverse video are the initial values.
When performing settings with operation keys only, set pin1 of the DIP switch to OFF (factory setting).
If pin 1 of the DIP switch is set to ON, the setting items indicated by will not be displayed.
For details on operations in run mode, refer to page 29.
Settings that cannot be performed with the DIP switch are performed with the operation keys.
Counting
speed
Tachometer
output
mode
Decimal
point
position
Prescale
value
Auto-zero
time
Average
processing
Startup
time
NPN/PNP
input mode
Display
color
Key protect
level
(HI-LO) (LO-LO)
(AREA) (HI-HI)
(No decimal
point)
(One digit
after decimal
point)
(Two digits
after decimal
point)
(Three digits
after decimal
point)
(No aver-
age pro-
cessing)
(Average of
8 measure-
ments)
(Average
of 2 mea-
sure-
ments)
(Average of
4 measure-
ments)
(NPN
input)
(PNP
input)
(Red) (Green)
(Red-green) (Green-red)
Output
allocation
Note: Displayed for H7CX-AU@ models only.

Omron H7CX Series Specifications

General

Input Signal	Contact
Power Supply	12-24 VDC or 100-240 VAC
Output	Relay
Mounting	Panel mount
Storage Temperature	-25 to 65°C (with no icing or condensation)
Weight	200 g
