Omron H8CA-S Series User Manual

H8CA-S
10
H8CA-S
■ CONNECTION OF LOAD CIRCUIT
CONTROL OUTPUT
Contact output type
Power supply for load
(250 VAC max.)
Load
Load
Power supply for load
(250 VAC max.)
(+)
(–)
Notes:
1. The load is turned on when the set count or time is up.
2. Be sure to connect terminal 8 when an inductive load is
connected.
Output delay time
The output delay time is the time from the application of the
count input signal of the preset value until the generation of
control output. The delay time differs depending on counting
speed and model of control output used, as shown in the
table below.
Common to
hours, minutes
and seconds
Type of Max. counting speed Output delay
control or rated time time
output
Contact
output
Solid-state
output
30 cps
1 kcps
30 cps
1 kcps
Reset input contact
(Resets the unit when
turned ON.)
Reset input NPN
transistor
(Resets the unit
when turned ON.)
30 VDC max.
(+)
(–)
Voltage input type
Reset input contact
(Resets the unit
when turned ON.)
E (30 VDC max.)*
R
Reset input NPN
transistor
(Resets the unit
when turned OFF.)
*At ``High'' level
4.7 E
4.7 + R (V) 5 V
E (30 VDC max.)*
30 VDC max.
Reset input PNP
transistor
(Resets the unit
when turned ON.)
R
Reset input NPN
transistor
(Resets the unit
when turned OFF.)
*At ``High'' level
4.7 E
4.7 + R (V) 5 V
■ CONNECTION OF COUNT INPUTS
No-voltage input type
■ RESET INPUT CONNECTION
Input 2
Input 1
(Counts when
turned ON.)
Input 1
Input 2
(Counts when
turned ON.)
30 ms max.
10 ms max.
30 ms max
2 ms max.
Note: The load is turned on when the set count or time is up.
Solid-state output type
