Omron H8CA-S Series User Manual

5
H8CA-SH8CA-S
Panel cutout
Note: Recommended panel
thickness is 1 to 3.2 mm.
Panel cutout conforms to
DIN 43700.
50
(1.97)
45
(1.77)
(1.97)
50
45 (1.77)
■ SOCKETS
11-Pin Sockets
P2CF-11 Bottom Surface or Track Mounting Socket
Eleven
M3.5 x 7.5
sems
Two
4.5 dia.
mounting
holes
7.8
4
3
4.5
(Top view)
Mounting holes
Two 4.5 dia. socket
mounting holes
40 ±0.2
35.4
(1.57)
Terminal arrangement
P3GA-11 Back Mounting Socket
Terminal arrangement
■ PANEL MOUNTING ADAPTER
Y92F-30 Mounting Adapter
Adapter installs behind the panel. It is ideal for side by side installation. Use a P3GA-11 socket.
Unit: mm (inch)
Dimensions
■ H8CA-S COUNTER/TIMER
Adapter for flush
mounting Y92F-30
P3GA-11 back connecting
socket
48
(1.89)
48
(1.89)
48
(1.89)
78
(3.07)
6
(0.24)
0.7
(0.03)
13.6
(0.54)
8
(0.31)
91.9
(3.62)
Panel
63.7
(2.51)
58
(2.28)
8
(0.31)
74
(2.91)
max.
31.2
(1.23)
max.
50
(1.97)
max.
