UUNIT DISPLAY
7
Display
Heart Symbol
Memory Value Symbol
(Displayed when
using memory.)
Average Value Display
(Displayed when using
memory, average
value for last three
measurements.)
Cuff Deflation Symbol
Pulse Display
Diastolic Blood Pressure
Systolic Blood Pressure
Date/Time Display
Battery Low Symbol
Irregular Heartbeat
Symbol
IRREGULAR HEARTBEAT SYMBOL
When the monitor detects an irregular rhythm two or more times
during the measurement, the Irregular Heartbeat Symbol ( )
will appear on the display with the measurement values.
The irregular heartbeat rhythm is defined
as a rhythm that varies by more than
or less than 25% from the average
rhythm detected while the monitor
is measuring the systolic and
diastolic blood pressure.
If the irregular heartbeat symbol ( )
displays with your measurement
results we recommend you consult your
physician. Follow the directions of your doctor.
Normal Heartbeat
Irregular Heartbeat
Pulse
Blood
pressure
Pulse
Blood
pressure
Short Long
HEM-609 Final 4/7/05 9:01 AM Page 7
