11
IRREGULAR HEARTBEAT SYMBOL ( )
When the monitor detects an irregular rhythm two or more times
during the measurement, the Irregular Heartbeat Symbol ( ) will
appear on the display with the measurement values.
An irregular heartbeat rhythm is defined
as a rhythm that varies by less than 25%
from the average rhythm or 25% more
than the average rhythm detected while
the monitor is measuring the systolic
and diastolic blood pressure.
If the irregular heartbeat symbol ( )
displays with your measurement results,
we recommend you consult your
physician. Follow the directions of
your doctor.
MOVEMENT ERROR SYMBOL ( )
The Movement Error Symbol is displayed if you move your body
during the measurement. Please remove the arm cuff, and wait 2-3
minutes. Take another measurement.
USER ID SYMBOL ( / )
The USER ID Symbol indicates USER A or USER B as selected by
the user to take a measurement or when using the memory function.
The USER ID Symbol is not displayed when using the Guest Mode to
take a measurement.
Normal Heartbeat
Irregular Heartbeat
Pulse
Blood
pressure
Pulse
Blood
pressure
Short Long
DISPLAY SYMBOLS
HEM-7080-updated Sept 22.qxd 9/22/06 3:46 PM Page 11
