10-8
DeviceNet Connection Hardware Section 8-3
Additional Informa-
tion for DeviceNet
Note 1. The product specifications of these cables are identical to the OMRON ca-
ble specifications.
2. The cables made by Allen-Bradley are stiffer than the cables made by
OMRON and Nihon Wire & Cable Company Ltd., so do not bend the Allen-
Bradley cables as much as the others.
Other DeviceNet communications cables are available from the following manufacturers. For details, refer to
the product catalogs on the ODVA web site (http://www.odva.astem.or.jp/) or contact the manufacturer directly.
DeviceNet Connector
Crimp Terminals for DeviceNet Communications Cables
Terminating Resistors for DeviceNet Network
A Terminating Resistor can also be connected to a T-branch Tap or a one-branch Power Supply Tap.
DVN24-500G Thin Cable: 5 wires, 500 m Nihon Wire & Cable
(See note 1.)
1485C-P1-C150 Thin Cable: 5 wires, 150 m Allen-Bradley (See
note 2.)
DCA1-5CN@@W1 Cable with shielded micro-size (M12) connectors on both ends (female
socket and male plug)
Cable length: 0.5 m, 1 m, 2 m, 3 m, 5 m, and 10 m
OMRON
DCA1-5CN@@F1 Cable with shielded micro-size (M12) connector (female socket) on one end
Cable length: 0.5 m, 1 m, 2 m, 3 m, 5 m, and 10 m
OMRON
DCA1-5CN@@H1 Cable with shielded micro-size (M12) connector (male plug) on one end
Cable length: 0.5 m, 1 m, 2 m, 3 m, 5 m, and 10 m
OMRON
DCA1-5CN@@W5 Cable with shielded connector on both ends (male plug on mini-size end,
female socket on micro-size end)
Cable length: 1 m, 2 m, 5 m, and 10 m
OMRON
Model Specifications Manufacturer
Model Specifications Manufacturer
HR31-5.08P-5SC (01) For node connection
Includes connector set screws
Hirose Electric
Model Manufacturer
HR31-SC-121: For Thin Cables Hirose Electric
HR31-SC-111: For Thick Cables
Model Specifications Manufacturer
DRS1-T Terminal-block Terminating Resistor, 121 Ω ±1% 1/4 W OMRON
DRS2-1 Shielded Terminating Resistor (male plug), micro-size (M12)
DRS2-2 Shielded Terminating Resistor (female socket), micro-size (M12)
DRS3-1 Shielded Terminating Resistor (male plug), mini-size
To Next Page
