3-6
Specifications Section 1-2
Overview
1-2-2 DeviceNet General Specifications
Item Specifications
Supply voltage DeviceNet power supply: 24 VDC (internal circuit)
Allowable voltage range DeviceNet power supply: 11 to 25 VDC
Current consumption DeviceNet power supply: 50 mA max. (24 VDC)
Vibration resistance Vibration: 10 to 55 Hz
Acceleration: 50 m/s
2
Shock resistance
150 m/s
2
max. 3 times each in 3 axes, 6 directions
Dielectric strength 2,300 VAC for 1 min. between all the external terminals and case
Insulation resistance 20 MΩ min. (at 500 VDC)
Ambient temperature
−10 to 55°C (with no condensation or icing)
Ambient humidity 25% to 85%
Storage temperature
−25 to 65°C (with no condensation or icing)
Enclosure rating IP00 (connector)
Memory protection EEPROM (100,000 write operations)
Weight DeviceNet connector: Approx. 8 g
Crimp terminals: Approx 1 g (each)
