Omron K3TJ - Measuring Ranges; Parameter List

K3TJ
K3TJ
6
Characteristics
Input signal
DC voltage/current (4 to 20 mA, 1 to 5 V, 0 to 5 V, and 0 to 10 V)
A/D conversion method
Double integral method
Sampling time
0.5 s
Display refresh period
0.5 s
Process value averaging method
Simple average/movement average
No. of process value averaging
operation
1, 2, 4, or 8 times
Max. displayed digits
4 digits (--1,999 to +9,999)
Display
7-segment red or green LED with a character height of 14.2 mm
Decimal display
Selected by the Up and Down Keys and parameter selector
Scaling function
Shift/Scaling adjustment is possible with the Up and Down Keys and parameter selector
Scaling range
--1,999 to +9,999
Zero-limit range
0to99digits
Overflow display
Flashes
Zero-suppress function
Available
External control
Process value hold (by short-circuiting the rear terminals)
Enclosure rating
Front panel: IP51 (see note)
Case: IP20 Refer to IEC
Terminals: IP00
Memory protection
Non-volatile memory (no backup battery is required)
Note:
IP51 is ensured with the Water-resistive Soft Front Cover, which can be ordered separately. Without the Water-resistive Soft Front
Cover, the front panel meets the requirements of IP50 instead.
Measuring Ranges
Measuring range Input impedance Reliability Max. permissible continuous load
Voltage (DC)
1to5VDC 1M
!
"
0.1%rdg
"
1 digit
"
250 V
g
(
)
0to5VDC 1M
!
"
0.1%rdg
"
1 digit
"
250 V
0to10VDC 1M
!
"
0.1%rdg
"
1 digit
"
250 V
Current (DC) 4to20mADC 100
!
"
0.1%rdg
"
1 digit
"
50 mA
Note:
The measurement accuracy values stated in the above table are guaranteed at an ambient temperature of 25

5
#
C.
Parameter List
Parameter name Operation Setting method
Display shift By setting a shift value, the displayed value will be shifted and displayed.
Set with the
i
t
l
Scaling value By setting a scaling value, the input signal will be converted and displayed.
Negative value scaling is possible.
internal
parameter
s
e
l
e
c
t
o
r
a
n
d
k
e
y
Decimal point The decimal point position can be selected.
se
l
ec
t
or an
d
k
ey
input.
Average display Displays the process value for 4 s maximum after a simple average or movement
average process.
i
n
p
u
t
.
Zero-limit range input Zero will be displayed for any value below the zero-limit value.
2-digit step display Rounds the rightmost digit to 0, 2, 4, 6, or 8.
5-digit step display Rounds the rightmost digit to 0 or 5.
Rightmost digit at 0 Rounds the rightmost digit to 0.
Display brightness adjustment Adjusts the brightness of the display to one of three levels.
