Omron K3TJ - Installation; External Connections

K3TJ
K3TJ
14
Dimensions
Note:
All units are in millimeters unless otherwise indicated.
Panel Cutouts
75 min.
120 min.
LED Display Character Size
14.2 mm
7.8 mm
45
+0.6
-- 0
92
+0.8
-- 0
66
98
92
96
48
3.5
45
Installation
External Connections
24 VDC
HOLD GND
GND0to10VDC
0to5VDC
1to5VDC
4to20mADC
INPUT POWER
321 4 5 6 7 8 9
100to240VAC
Note:
Terminals 3 and 6 are connected internally. The power supply terminals are insulated from other circuits.
Connection Example with Inverter
+
--
E
0to10VDC
1
GND
3
3G3
j
V
8888
Analog
monitor
Analog output
K3TJ
R
S
T
R
S
T
U
V
W
IM
Three-phase
power supply
Circuit breaker
Inverter ’s
internal
circuitry
