Omron NJ Series

10. Appendix 2 Setting the Tag Data Links Using the Software
10.3.5. Settings in the Watch Tab Page
To check data that is sent and received, make settings in the Watch Tab Page.
1
Select Watch Tab Page from the
View Menu.
2
The Watch Tab Page 1 is displayed
in the lower section of the Edit
Pane.
3
Enter the following names in the
Name Column on the Watch Tab
Page for monitoring. To enter a new
name, click a column stating Input
Name.
EIPOutput.CommonControlFlag.F[
0](EXE)
EIPOutput.CommandCode
EIPOutput.CommandParam1
EIPInput.CommonStatusFlag.F[0](
FLG)
EIPInput.CommandCodeEcho
EIPInput.ResponseCode
EIPInput.ResponseData
69
