6-9 Hardware Check
6-9 Hardware Check
The hardware check is used to check the following functions.
Item Function
LCD check Checks the LCD.
Touch switch check Checks touch panel input.
6-9-1 LCD Check
This function checks whether the LCD (screen display) is operating normally.
Check the LCD by using operations from the Hardware Check Tab Page in the System Menu,
as follows:
1. Press the LCD Check Button to switch to the LCD Check Screen.
2. Press the Back Button to return to the Hardware Check Screen.
6-58

Omron ns series Specifications

General

Backlight	LED
Power Supply	24 VDC
Display Type	TFT LCD
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Interface	Ethernet, USB
Memory	Varies by model
Operating Temperature	0 to 50°C
Protection Level	IP65 (front panel)
Storage Temperature	-20 to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s²
Power Consumption	Varies by model
