3-7 Installing the Video Input Unit
3-7-4
Connecting to Vi
deo Input Connectors
Use the follo
wing method to connect cameras to the V
ideo Input Unit mounted to the PT
.
Note
The tensile load of the cable is 30 N m
aximum.
Do not exceed maxim
um load
●
Connecting to Video Input Connectors
1.
Inser
t the BNC socket on the camera’
s video output cable into a video input connector
.
2.
After inser
t
ing the BNC sock
et, twis
t it clockwise until it locks into place.
T
wi
st clo
ckwi
se.
3-34
