Appendix 8 Standard Models
CPU Units That Connect to PTs via Controller Link
PLC Series CPU Unit Specifications
CS Series All CS-series CPU Units Mount a CS1W-CLK21 Controller
Link Unit.
CJ Series All CJ-series CPU Units Mount a CJ1W-CLK21 Controller
Link Unit.
C200HE/HG/
HX Series
(See note 1.)
C200HE-CPU32 (-Z)
C200HE-CPU42 (-Z)
C200HG-CPU33 (-Z)
C200HG-CPU43 (-Z)
C200HG-CPU53 (-Z)
C200HG-CPU63 (-Z)
C200HX-CPU34 (-Z)
C200HX-CPU44 (-Z)
C200HX-CPU54 (-Z)
C200HX-CPU64 (-Z)
C200HX-CPU65-Z
C200HX-CPU85-Z
Mount a C200HW-CLK21 Controller
Link Unit.
CQM1 Series CQM1H-CPU51
CQM1H-CPU61
Mount a CQM1H-CLK21 Controller
Link Unit.
CV Series
(See note 2.)
All CV-series CPU Units
CVM1 Series
(See note 2.)
All CVM1-series CPU Units
Mount a CVM1-CLK21 Controller
Link Unit.
Note 1. The following are required when mounting a Controller Link Unit:
C200HW-COM01/COM04 Communications Board
C200HW-CE001/CE002/CE012 Bus Connection Unit
2. Always set routing tables when using a CVM1/CV-series CPU Unit manufactured in April
1996 or earlier. The manufacturing date can be checked with the 4-digit lot number given
on the side of the CPU Unit, as shown below.
The rightmost digit of the year, 1996
in this example
.........Manufactured April 199664
@@
Lot No.:
The month of manufacture
1 to 9 = January to September
X to Z = October to December
Refer to the Controller Link Units Operation Manual (W309) for setting methods for the
PLC Controller Link Units.
RS-232C/RS-422A Converters
Model Specifications
NT-AL001 RS-232C: 9-pin connector
RS-422A: 8-pin terminal block
NS-AL002 RS-232C: 9-pin connector
RS-422A: 8-pin terminal block
CJ1W-CIF11 RS-232C: 9-pin connector
RS-422A: 5-pin terminal block
Reference • When a CJ1W-CIF11 Conversion Adapter is used, the total transmission length is
50 m.
• If NT-001/NS-002 Link Adapters are used together with CJ1W-CIF11 Conversion
Adapters on the same transmission path, the total transmission length is also
50 m.
A-50
